AUTOOL BT760 Car Battery Tester 12V 24V CCA Analyzer Automotive Batteries Charging Test Auto Diagnostic Tools with Thermal Print

1. Product Summary

1)BT760 can do tests on automotive and motor batteries such as battery test, cranking test, charging test and maximum load test.

2)Test all automotive cranking lead acid battery, including ordinary lead acid battery, AGM flat plate battery, AGM spiral battery, and Gel battery, etc.

3)Directly detect bad cell battery.

4)Polarity reverse connection protection, reverse connection will not damage the tester or affect the vehicle and battery.

5)Directly test the battery with power shortage, no need to fully charge it before testing.

6)Testing standards include currently the world’s majority of battery standards, CCA, JIS,

DIN, IEC, EN, SAE, GB.

7)Support multiple languages, customer can select different language package, which including English, Russian, Spanish, French, German, etc. Other customized language version are also provided.

2. Product Function

Battery test is mainly targeted to analyze the battery healthy status to calculate the actual cold cranking capability of the battery and the aging extent, which provide reliable analysis evidence for the test and maintenance of the battery. It notifies the user to replace battery in advance when the battery getting aged.Cranking test is mainly to test and analyze the starting motor. Through testing the actual required cranking current and cranking voltage of the starting motor, it can find out whether the starting motor works fine. There are several reasons why the starting motor is abnormal: lubricating system fault causing the starting loaded torque increasing or rotor friction of the starting motor causing the increasing friction of the starting motor itself.Charging test is to check and analyze the charging system, including generator, rectifier,rectifier diode, etc., thus to find out whether the output voltage of the generator is normal,the rectifier diode works fine and the charging current is normal. Suppose one of the above mentioned parts is not in normal situation, it will lead to over charge or incomplete charge of the battery, thus the battery will be quickly damaged and also greatly shorten the using life of other loaded electrical appliance. Load test is the test of battery pack, DC power supply, UPS backup battery maintenance and capacity detection.

3. Working Steps

Shake the clamps back and forth to make sure they are well connected. Tester requires the two clamps well connected with the battery poles, otherwise, the test can not go on. The red to the positive and the black to the negative, then the tester display will show the starting interface.

* When the measured battery voltage is lower than 6.0V, the normal test cannot be performed. Press OK to continue.

* Cold Cranking Amps Measure Range:

CCA (USA): 20-3000; IEC (International): 20-2500;

EN (Europe): 20-3000; DIN (Germany): 20-2500;

JIS (Japan): 26A17-N200Z ; Other Species.

2.Voltage Measure Range: 6v~ 30v DC.

Battery test, Cranking test, Charging test, Maximum load testMULTI-LINGUAL FUNCTON

Supports English, Russian, Spanish, Portuguese, FrenchGerman, Italian, Thai, Korean, Chinese, Japanese, Turkish, etc. More than ten languagesAPPLED TO WIDE RANGE MODELSConsequences of using poor batteries

Vehicle electrical failure. Power system gets damaged. Break down and failure to start

Support 6- 32V battery test, fast and convenient. 2.8 inch HD color screen with clear displayu. Reverse connection protection, safe and reliabler. Powerful functions, accurate test results. Switch more than 10 commonly used languagesSupport 6-32V battery testing

With a large test range. BT 760 can also support the battery test of trucks and motorcycles compared to the testers that can only test cars on the marketSupport one-click data printing

After the battery test is completed, the test results can be printed for easy storage

Starting Test

The main purpose is to know whether the starting motor is working properly, by testing the actual starting current and voltage of the starter motorCharging Test

By checking and analyzing the charging system, including generators,rectifiers, rectifier diodes, etc. check whether the output voltage of the generator is normal, if rectifier diodes work normally, charging current is normal or notMaximum Load Test

To ensure that the battery can operate normally without exceeding the maximum workload
